Support 420°C Hotend
We are the first one to publish 420°C high temperature nozzle to 3d printer market. This kind of nozzle allow to print with a variety of filaments. The nozzle height can also be micro adjusted. (Default support 260°C, contact us for 420°C.)
High Precision & High Speed
We exclusively research and develop the extruder feeding system and guide rail, which support high-speed printing. And it allows to extrude filament steady without block.
Stability
The whole-steel body not only ensure the stability when printing, but also extend the usage period greatly. Its optimization and cooperation of overall structure ensure the sustainable and efficient operation. The first batch of CreatBot 3D printers have been working for 9 years and more than 30,000 hours.
Fully Enclosed High-Temperature Chamber
Fully enclosed chamber can block all external interference and reduce noise. Hot chamber can provide constant room temperature so that model won’t deform when printing.
Outage Restored & Filament Detection
The printer will automatically memorize the current position and save print data. Lower the platform and withdraw filament when power off suddenly. It will continue to print from the last stopped point after power’s on.
The printer will avoid invalid printing by stoping print and warning when filament runs out.
Touch Screen
The printer have all-English-menu touch screen which is easy operate and friendly use. One key to warm,one key to print as p-4 rounded-lg bg-light border as many other shortcut keys.
Efficiently Platform & 150°C Hotbed
The hotbed is made of heatable aluminium PCB, which can be heat up to 150°C fast. The platform is attached with 3d printing stickers buildtak. Printed object can be stick on the buildtak tightly and won’t get deformed.
Printing |
Print Technology |
Fused Deposition Modeling |
Build Volume |
160*160*200 mm |
Number of Nozzles |
Single |
Layer Resolution |
0.05 mm |
Filament Diameter |
1.75 mm |
Filament Compatibility |
PLA, ABS, Carbon Fiber, Wood, Nylon, PC, PTEG, HIPS, PP, Flexible, TPU, PVA,PEEK, ULTEM (F160-PEEK) etc. |
Nozzle Diameter |
0.4 mm(0.3 0.5 0.6 0.8 1.0 mm) |
Print File Type |
STL, OBJ, AMF, Gcode |
Electrical |
Power Requirements |
100V-110V or 200V-240V / 50-60Hz (Depending on your country's default voltage) |
Rated Power |
F160: 340W, F160 PEEK: 1100W |
Screen |
4.3" Touch Screen with Multi-language |
Storage Media |
U Disk |
Connectivity |
USB |
Mechanical |
Construction |
Power-Coated Steel, Aluminum Casting for Motion Components, POM etc |
Build Plate |
Heatable Aluminium PCB with BuildTak |
Build Plate Leveling |
Manually |
Extruder |
Directly Drive |
Stepper Motors |
1.8°Step Angle with 1/16 Micro-stepping |
X Y Positioning Precision |
12.7 μm |
Z Positioning Precision |
1.25 μm |
Speed |
Best Printing speed |
70 mm/s |
Max. Printing speed |
300 mm/s |
Temperature |
Ambient Operating Temperature |
15-32 ℃ |
Max. Nozzle Temperature |
F160: 260 ℃ F160-PEEK: 420 ℃ |
Max. Bed Temperature |
150 ℃ |
Max. Chamber Temperature |
70 ℃ (F160-PEEK) |
Software |
Software |
CreatWare, Simplify 3D, Cura, Slic3r, etc |
Supported File Types |
STL,OBJ,AMF |
Operating Systems |
Win7/8/10, macOS |
Special Function |
Outage Restored |
Save data when power is off |
Filament Detection |
Pause printing when filament run out |
Automatic Shut-down |
Turn off the power automatically when printing is complete |
Size & Weight |
Product Dimensions & Weight |
370*320*490 mm 18 kg |
